A dry van container is a type of shipping container that is enclosed and designed to keep cargo dry and protected from the elements during transportation. It is commonly used to transport a wide range of goods, including electronics, clothing, building materials, and more. The dry van shipping container is made from corten steel and has marine grade plywood floors which help keep cargo secure. Dry van containers come in various sizes, ranging from 20 feet up to 40 feet in length.
In addition to different sizes, dry van containers are available in three different door configurations – standard cargo doors, cargo doors on both ends and open-side containers.
The standard end door configuration has a single set of cargo doors located at the end of the container, which is secured with locks and seals to keep the cargo safe during transit. This is the most common type of dry van container.
The tunnel container has cargo doors at both ends of the container, allowing for quick and easy loading and unloading from either end. This design is especially useful for cargo that needs to be accessed frequently or needs to be loaded and unloaded quickly.
The open-side container has one or both
sides of the container designed with doors, rather than solid walls. These
doors can be opened to provide convenient access to the cargo from the side of
the container. This is particularly useful for cargo that is awkwardly shaped
and difficult to load through the end doors.
Each configuration is designed to suit different shipping requirements and offer more flexibility during the loading and unloading.
Here are the approximate dimensions of the
most common dry van shipping container sizes.
10 ft | 20ft | 40ft | 40ft HC | 45ft | |
---|---|---|---|---|---|
External dimensions | 10’ long 8’ wide 8’6” high. |
20’ long 8’ wide 8’6” high. |
40’ long 8’ wide 8’6” high. |
40’ long 8’ wide 9’6” high (1ft taller) |
45’ long 8’ wide 9’6” high (1ft taller) |
Internal dimensions | 9’ 3” long 7’ 8” wide 7’ 9” high |
19’ 3” long 7’ 8” wide 7’ 9” high |
39’ 5” long 7’ 8” wide 7’ 9” high |
39’ 5” long 7’ 8” wide 8’ 10” high |
44’ 5” long 7’ 8” wide 8’ 10” high |
How wide is the door? | 7’ 8” wide 7’ 5” high |
7’ 8” wide 7’ 5” high |
7’ 8” wide 7’ 5” high |
7’ 8” wide 8’ 6” high |
7’ 8” wide 8’ 6” high |
What is the internal floor space? | 72 sq. ft. | 147 sq. ft. | 302 sq. ft. | 302 sq. ft. | 340 sq. ft. |
What is the volume? (Cubic Feet) | 550 cu. ft | 1,144 cu. ft | 2,343 cu. ft. | 2,670 cu. ft. | 3,009 cu. ft. |
What does it weigh empty? (Tare) | 2800lbs | 4,000 - 5,000 lbs | 8,000 lbs | 9,000 lbs | 9,810 lbs |
20ft | 40ft | 40ft High Cube (HC) |
45ft High Cube (HC) | |
---|---|---|---|---|
External dimensions | 20’ long 8’ wide 8’6” high. |
40’ long 8’ wide 8’6” high. |
40’ long 8’ wide 9’6” high (1ft taller) |
45’ long 8’ wide 9’6” high (1ft taller) |
Internal dimensions | 19’ 3” long 7’ 8” wide 7’ 9” high |
39’ 5” long 7’ 8” wide 7’ 9” high |
39’ 5” long 7’ 8” wide 8’ 10” high |
44’ 5” long 7’ 8” wide 8’ 10” high |
Side door opening | 18' 8" 31/64 wide 7' 1" 25/64 high |
18' 8" 31/64 wide 7' 1" 25/64 high |
38' 8" wide 7' 7" high |
38' 8" wide 7' 7" high |
What is the internal floor space? | 147 sq. ft. | 302 sq. ft. | 302 sq. ft. | 340 sq. ft. |
What is the volume? (Cubic Feet) | 1,144 cu. ft | 2,343 cu. ft. | 2,670 cu. ft. | 3,009 cu. ft. |
What does it weigh empty? (Tare) | 4,000 - 5,000 lbs | 8,000 lbs | 9,000 lbs | 9,810 lbs |
We offer a wide selection of containers for all your needs. From dry vans and refrigerated to specialized containers, we have the right option for you – no matter the size or purpose. Our purchasing power ensures that you’re always getting the best price available. So, whether you need it for long-distance transportation of cargo or need a container for storage, or another project, our selection is sure to have what you’re looking for!
On-Site Storage Solutions is a leader in providing rental shipping containers for temporary or long-term needs, at the lowest rates available. Rental rates start as low as $99 a month (some areas may require sales tax), just give us a call at (888) 997-9085, and we’ll walk you through the container rental process.
On-Site Storage Solutions is proud to present a Rent-To-Own Option in partnership with My Container Rental. Call us at (888) 977-9085 or select from our website the payment plans that suit you best – including 6, 12 18, and 24 Months, as well as long-term programs.
At On-Site Storage Solutions, we pride ourselves on being one of the leading container companies in America. All our containers go through a thorough inspection before they are shipped out. Ensuring that our customers get nothing but high-quality containers. Plus, we guarantee satisfaction with every order. If you’re unhappy with a purchase for any reason whatsoever, we offer a full refund minus delivery and pick-up fees. Get the secure storage solutions you need today at an affordable price with On-Site Storage Solutions!
